Installation method: Recessed.
Protection level: IP20.
Light category: ∥ class.
Light source type: COB.
Shell body: aluminum.
Reflector: professionally designed by TRACE-PRO according to reflection theory,the light can be performed in highest efficiency.
Diffuser: glass.
Driver: Adopting isolated flicker free constant current driver supply, different brands of driver supply can be selected.
Widely used in shops, hotels, offices, exhibition halls, restaurants and so on.
Product Code | Voltage | Input/Output | CRI | CCT | IES | Lumen Output | Beam Angle | Dimensions (mm) | Cut Size (mm) | Inquiry |
![]() |
AC220-240V | 30W/28W | ≥80 | 3000K 4000K 6500K | 3200LM 3350LM 3500LM | 90° | φ228*H50mm | φ200-210mm | ||
![]() |
AC220-240V | 15/14W | ≥80 | 3000K 4000K 6500K | 1600LM 1700LM 1800LM | 90° | φ170*H45mm | φ140-150mm | ||
![]() |
AC220-240V | 10.5/9.5W | ≥80 | 3000K 4000K 6500K | 1050LM 1100LM 1150LM | 90° | φ120*H43mm | φ95-105mm | ||
![]() |
AC220-240V | 7/6W | ≥80 | 3000K 4000K 6500K | 800LM 820LM 840LM | 90° | φ90*H35mm | φ70-80mm |
Lifud
OSRAM
