Installation method: Recessed.
Protection level: IP20.
Light category: ∥ class.
Light source type: COB.
Shell body: aluminum.
Reflector: professionally designed by TRACE-PRO according to reflection theory,the light can be performed in highest efficiency.
Diffuser: glass.
Driver: Adopting isolated flicker free constant current driver supply, different brands of driver supply can be selected.
Widely used in shops, hotels, offices, exhibition halls, restaurants and so on.
| Product Code | Voltage | Input/Output | CRI | CCT | IES | Lumen Output | Beam Angle | Dimensions (mm) | Cut Size (mm) | Inquiry |
| WL6705-3SL15W-B | AC220-240V | 15/13W | ≥80 | 3000K 4000K 6500K | 1500lm 1560lm 1620lm | 24/38° | φ105*H99mm | φ95 | ||
| WL6705B-2SL8W-B | AC220-240V | 12/10W | ≥80 | 3000K 4000K 6500K | 1250lm 1320lm 1400lm | 24/38° | φ85*H93mm | φ75 | ||
| WL6705A-2SL8W-B | AC220-240V | 8/6.5W | ≥80 | 3000K 4000K 6500K | 900lm 950lm 1000lm | 24/38° | φ85*H76mm | φ75 | ||
| WL6705-1SL5W-B | AC220-240V | 5/4W | ≥80 | 3000K 4000K 6500K | 650lm 700lm 750lm | 24/38° | φ63*H63mm | φ55mm |
