Light source:MCOB
Shell:adopts high-quality die-casted aluminum, performs well in cooling.
Shape: looks elegant and natural. The two movable rings can adjust at X and Y direction by ±40 degrees.
Reflector: professionally designed by TRACE-PRO according to reflection theory, the light can be performed in highest efficiency.
Diffuser: cover by glass, at 95% transmission rate.
Constant current control driver; outputs constant current, in low power consumption. It’s directly attached on the lamp shell.
Output light:constant, without glare. Light consumption is less than 3% after 2000 hours lighting.
Beam angle: 20,36 degrees.
Widely used for main lighting, applied in shops, hotels, offices, exclusive shops, showrooms and so on.
Product Code | Function | Voltage | Input/Output | CRI | CCT | IES | Lumen Output | Beam Angle | Dimensions (mm) | LED rail system | Inquiry |
WTR056F-2SL10W-TC | Standard | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*61*115 | 3line 4line(optional) DALI(optional) | ||
WTR056F-2SL10W-MCT | Mechanical switch control CCT | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*61*115 | 3line 4line(optional) DALI(optional) | ||
WTR056F-2SL10W-MCTDIM | Mechanical switch control CCT & dimmable | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*61*115 | 3line 4line(optional) DALI(optional) | ||
WTR056F-2SL-10W-SCT | Switch control CCT | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*61*115 | 3line 4line(optional) DALI(optional) | ||
WTR056F-2SL10W-SCTDIM | Switch control CCT & dimmable | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*61*115 | 3line 4line(optional) DALI(optional) | ||
WTR056F-2SL10W-RMCDIM | Intelligent remote control | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*61*115 | 3line 4line(optional) DALI(optional) | ||
WTR056F-2SL10W-DIM | Triac dimmable | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*61*115 | 3line 4line(optional) DALI(optional) | ||
WTR056F-2SL10W-DALDIM | DALI dimmable | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*61*115 | 3line 4line(optional) DALI(optional) | ||
WTR056F-2SL10W-FRE | Fresh light | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*61*115 | 3line 4line(optional) DALI(optional) | ||
WTR056-2SL10W-TC | Standard | AC100-240V | 12.8W/10.8W | ≥80 | 6400K 4000K 3000K | 1525LM 1450LM 1375LM | 20°/36° | 125*60*115 | 3line 4line(optional) DALI(optional) |
